XLB-S12T Automatic Screw Locking Machine
  • XLB-S12T Automatic Screw Locking Machine
XLB-S12T Automatic Screw Locking Machine
XLB-S12T automatic screw locking machine supports two types of robotic arms for automatic material retrieval, sliding arm and belt line methods
  • Consultation Hotline: 134-1280-6689
    133-1080-8818
  • Equipment Introduction

    XLB-S12T automatic screw locking machine, also known as XLB-S12T automatic screwing machine or XLB-S12T automatic screwing machine, is an essential equipment for automated production in modern industry. It can reduce production costs while greatly improving production capacity.


    Equipment features

    1: The XLB-S12T automatic screw locking machine adopts a single electric batch and dual tracks, with parallel product picking and placing time and locking time, resulting in high efficiency.

    2: The equipment supports pre process insertion and post process removal, achieving low-cost operation without dedicated personnel.

    3: The operating speed and stability of XLB-S12T automatic screw locking machine are at the forefront of the industry, with an average of 1.0-1.3 seconds per screw.

    4: The equipment adopts a universal fixture design, making it widely applicable and enhancing its value.

    5: The device supports two types of robotic arm automatic material retrieval, sliding arm and belt line methods.

    6: It supports copying programs for USB memory (USB flash drive) models.

    7: The XLB-S12T automatic screw locking machine supports automatic detection and alarm highlights for missing locks, slipping teeth, and floating height.

    8: The device supports one click reset of system parameters.

    9: The XLB-S12T automatic screw tightening machine supports automatic processing of residual screws to avoid locking the product.


    Application industry

    Screw lock attachments for various miniaturized electronic products, such as mobile phones, electronic watches, remote controls, calculators, etc;

    Equipment Name: XLB-S12T Automatic Screw Locking Machine

    Machine size: 650 * 550 * 650mm (L * W * H)

    Working size: 130 (L) * 200 (W) * 60 (h)

    Drive mode: stepper motor servo motor

    Positioning accuracy:± 0.02mm

    Drive structure: slide synchronous belt

    Program storage: supports 100 products

    Control system: advanced PLC touch screen control system

    Screw processing method: vacuum suction

    Supplier model: HIOS or Quicher

    Electric batch model: HIOS or other

    Air pressure: 0.4-0.8MPA

    Weight: 60 kilograms
